FOTRIC 345M Thermal Imaging Camera Series

  • 320 x 240 thermal resolution
  • thermal sensitivity of <0.04℃@30℃
  • Manual Focus Mode.
SKU FOTRIC 345M Series Category Tags ,
Manufacturer:

Call for price

Description

FOTRIC 345M Thermal Imaging Camera Series

The FOTRIC 345M Series is an advanced hand-held thermal imaging camera with 320 x 240 thermal resolution.

It has a thermal sensitivity of <0.04℃@30℃ with a superior imaging display on 5” LCD touch screen.

Engineered to withstand 2 meters (6.5 feet) drop with standard lens.

Other advanced features include inter-changeable Lens options, and powerful AnalyzIR report software.

The FOTRIC 345M standard lens has a FOV of 25°x19°. Other lens options include:

  • Wide-angle:44°×34°, IFOV:2.4mrad
  • Telephoto:12°×9°, IFOV:0.65mrad

Product Features

  • 320 x 240 thermal resolution
  • thermal sensitivity of <0.04℃@30℃
  • Built-in 13 MP digital camera
  • 5″ HD IPS touch screen
  • Laser ranger for accurate distance and area measurement
  • Manual Focus Mode
  • Minimum focus distance 0.1m
  • Interchangeable lenses
  • Multiple connection interfaces
  • Up to 128GB micro SD memory card
  • Built-in speaker for temperature alarm
  • Tripod for 1/4″ standard mounting
  • AI programmable key, for quick access
  • Batteries life over 4 hours per battery
  • Ergonomic handheld design
  • FREE Report Software included



The FOTRIC 345M is supplied with lens, lens cover, batteries, battery charger, power adapter, USB type-C to USB interface cable, micro HDMI to HDMI interface cable, SD card, SD card reader, accessory bag (wrist strap, 2 wrist strap holders, 2 M4 * 8 screws, lanyard, Allen wrench), information bag (packing list, user manual, calibration certificate, certificate of QC, certificate of inspection, warranty card, USB disk), portable soft bag, and portable hard case.



FOTRIC 340 Series Comparison

Key Features
348A Series
347A Series
346A Series
345A Series
345M Series
Infrared Resolution 640 x 480 480 x 360 384 x 288 320 x 240 320 x 240
Super Resolution (SR) 1280 x 960 960 x 720 768 x 576 640 x 480 640 x 480
Thermal Sensitivity (NETD) < 0.03℃ @30℃ < 0.04℃ @30℃
Temperature Measurement Range -20℃ to 1550℃ -20℃ to 650℃
IFOV with Standard Lens 0.68mrad 0.91mrad 1.14mrad 1.36mrad
Digital Zoom 1-10x,Continuous adjustment of roller 1-8x
User-definable Spot Markers 16 spot markers 12 spot markers
User-defined Measurement Boxes 12 (rectangle or circle) 8 (rectangle or circle)
User-defined Measurement Lines 8 measurement lines 4 measurement lines
Minimum Focus Distance 0.25m 0.1m
Focus Mode TurboFocus ™ Speedy Intelligent Autofocus system for continuous, laser distance, graphic contrast, manual Manual
Laser Measurement Distance, Length, and Area
Key Features Fotric 345M
Infrared Resolution 320 x 240
Thermal Sensitivity (NETD) <0.04℃@30℃
Temperature Measurement Range -20℃ to 120℃
0℃ to 650℃
smart switch between
User-definable Markers 12 spot markers; 4 (rectangle or circle); 8 measurement line
Focus Mode Manual
Field of View (FOV)- Standard Lens 25°×19°
Interchangeable Lens Options Wide-angle:44°×34°(<0.1m), IFOV:2.4mrad
Telephoto:12°×9°(<1m), IFOV:0.65mrad
AI Programmable Key Yes, for quick start
Frame Rate 30Hz
Lens Options Optional wide-angle lens and telephoto lens
Storage Memory 32GB SD memory card
Accuracy ± 2℃ or ± 2 %, whichever is greater (ambient temp between15℃~35℃)
On-screen Analysis Emissivity, Partially emissivity, Reflected temperature, Ambient temperature, Humidity and Distance.
Sound Alarms Area alarm; High temperature alarm and low temperature alarm
Display Gorilla Glass Explosion-proof IPS LCD
Display pixels: 1280*720,Display size: 5inch (landscape)
Build-in Digital Camera (visible light) 13-megapixel, industrial digital camera
Palettes 15 standard palettes, 3 colour isotherm, 15 inverted palettes
Image File Formats Standard JPEG with measurement data included
Video File Formats Full radiation thermal image video in IRS format;
standard MPEG4 non radiation video;
Remote Control Operations Remote display and control operation through Fotric AnalyzIR software
Battery Life Over 4 hours per battery
Battery Charging System Two-bay battery charger with LED display (12V, 3A)
Device Interface Support USB Type-C 3.0, Micro HDMI and SD card
Vibration EN 60068-2-6
Drop Engineered to withstand 2 meters (6.5 feet) drop with standard lens
Enclosure Rating IP54 (protected against dust, limited ingress; protection against water spray from all directions),
GB/T 4208-2017/IEC60529:2013
Shock EN 60068-2-6
Electromagnetic Compatibility

EN 61326-1:2013 ( EN 61000-6-2)
EN 61326-1:2013 Class A ( EN 61000-6-3)
FCC 47 CFR Part15 Class A (emission)

*Some features might be added or slightly altered according to the region and country
