LX-1000 Modular, Stand-alone Data Recorder

The LX-1000 Series provides highly reliable, portable data recorders designed to capture and record measurement data for testing and monitoring in a wide range of industrial and scientific applications.

SKU LX-1000 Category

Call for price


Modular, Stand-alone Data Recorder, LX-1000 from TEAC.

The LX-1000 Series provides highly reliable, portable data recorders designed to capture and record measurement data for testing and monitoring in a wide range of industrial and scientific applications. This modular based system can be individually customised to the requirements of each application. Up to four input modules with four channels each (two channels for CAN) can be configured. The expansion unit, which holds up to four additional input modules, can also be fitted to the main unit. Therefore, one compact unit can provide up to 64 recording channels and if four units are synchronised, up to 256 channels can be achieved.

Due to its compact size and fan-less operation, the LX-1000 can be placed in the immediate vicinity of the measurement source. This allows noise and vibrations in addition to other measurement data to be recorded without interference. A remote control with full-colour display enables visualisation of recorded data and operation from a distance.

Product Features

  • Modular concept
    Input channels can be customised in groups of four (analogue, strain, thermocouple or CAN can be recorded directly); dedicated Expansion Unit (AU-LX1000EPIO) for up to 16 additional input channels.

  • Up to 256 recording channels
    64-channel recording with one unit, 256 channels by synchronizing four units.

  • Fan-less design
    Allows data recording with no interference, and the absence of a cooling fan reduces maintenance costs.

  • Wide dynamic range
    A dynamic range of 120 dB ensures precise recording with a high signal-to-noise ratio.

  • Long-term recording
    Using high-capacity storage media allows long recording sessions.

  • Optional video synchronisation
    Can be synchronised to the TEAC VR-24 2-channel HD video recorder.

Product Configuration Main Unit LX-1000: Up to 4 amplifiers can be incorporated
Expansion Unit AU-LX1000EPIO: Up to 4 amplifiers can be incorporated
Maximum Number of Channels 64 Channels
Cooling No external cooling required. (fan-less up to 32 Channels)
Sampling frequencies 102.4kHz Series: 102.4k, 51.2k, 25.6k, 12.8k, 5.12k, 2.56k, 1.28kHz
100kHz Series: 100k, 50k, 20k, 10k, 5k, 1kHz
96kHz series: 96k, 48k, 24k, 12k, 6k, 3k, 1.5kHz
65.54kHz: 65.536k, 32.768k, 16.384k, 8.192k, 4.096k, 2.048k, 1.024kHz
Low Speed Sampling: 500, 200, 100, 50, 10, 5, 1Hz
Resolution 16bit / 24bit
Interface for PC Gigabit Ethernet x 1 port
Recording Media SDHC / SDXC card (8GB - 128GB, class 10 or more) / PC Direct Recordable
Maximum Recording Rate 3.2Mbyte/s  40kHz band (102.4kHz sampling) x 16-bit x 16ch
External Dimensions Main Unit: 300H x 65W x 200D mm
Expansion Unit: 300H x 44W x 200D mm
Operating Temperature and Humidity Range 0 to 40°C, 10 to 80% (no condensation)
Storage Temperature and Humidity Range -20 to 60°C, 5 to 90% (no condensation)
Synchronized Operation LX-1000 Synchronization: Up to 4 units
VR-24 Synchronization: 1 unit
Pulse Input (Standard equipment) Number of Input Channels: 2ch
Input Connectors: BNC
Threshold Level: ±0.5 / 1 / 2.5 / 5 / 10 / 20V
Maximum Input Voltage: ±50V
Maximum Input Frequency: 450kHz
Input Impedance: 100kΩ
GPS Input (Standard Equipment) Number of Input Channels: 1ch
Input Connectors: DX10A-2 0S (50)
Recommended GPS Module: GARMIN GPS18x-5Hz
Voice Memo Input and Output Sampling Frequency: 8kHz
Resolution: 8bit
File Format: WAV
Power Consumption 16ch Model (AR-LXPA1000 x4): 30W approx.
32ch Model (AR-LXPA1000 x8): 47W approx.
48ch Model (AR-LXPA1000 x12): 64W approx.
64ch Model (AR-LXPA1000 x16): 81W approx.
Weight LX-1000 (consisting of AR-LXPA1000 x4): 3.1Kg approx.
AU-LX1000EPIO (consisting of AR-LXPA1000 x4): 2.3Kg approx.
Analogue Signal Input Amplifier
Number of Input Channels 4ch / module, DC/AC/IEPE (TEDS applicable) Selectable
Input Connector BNC (Z=50Ω type)
Input Format Unbalanced
Input Impedance  1MΩ
Input Range ±0.1 / 0.2 / 0.5 / 1 / 2 / 5 / 10 / 50V
Analogue - Digital Conversion Method ΔΣ Conversion Method
Dynamic Range 120dB (10V input range) FFT-based
High Pass Filter OFF / 5Hz (-18dB / oct Butterworth filter)
Weighting A curve, C curve or flat IEC-TYPE1
IEPE sensor constant current source DC 24V / 4mA
IEPE sensor interruption detection Each module has IEPE sensor interruption detection
Analogue Signal Output Amplifier
Number of Input Channels 4ch
Output Connector BNC (Z=50Ω type)
Output Format Unbalanced
Output Impedance 50Ω
Output Range Setting ±1 to 5V (selectable in 0.1V increments)
Over Range ± 127% (+2.08dB)
Digital - Analogue Conversion Method ΔΣ Conversion Method
CAN Module
Number of Input Ports 2 ports / module
Input Connector 9-pin D-sub rectangular connector
Compatible Protocol ISO-11898-1, 2.0A (11bitID) / 2.0B (29bitID)
Baud Rate 125 / 200 / 250 / 500 / 1000 kbps
Recording Mode All frames recording / ID Filtering / Data Signal Values
Bus Modes of Operation Normal / Listen Only
Strain Input Amplifier
Number of Input Channels 4 ch / module
Input Signal Type Strain / DC
Input Connector 7-pin Lemo,
Ø10 (EGG0B type)
Input Format Unbalanced, DC coupled
Input Impedance 1MΩ
Absolute maximum input voltage ±25V
Signal quantization bit depth 16 /24-bit
