DAS700 High Speed Universal 6 Ch Data Acquisition System

Sefram High Speed Data Acquisition Solution (up to 1 MSa/s (1μs)) for applications ranging from small sensor signal logging (process) to electrical power analysis.

SKU DAS700 Category
Manufacturer:

£8,190.00 ex VAT

Available on back-order

Description

The DAS700 is a High-Speed Recorder from Sefram that enables you to acquire multiple parameters: Voltage, Current (with shunt or Clamp), Temperature (thermocouples), measurements on sensors (e.g. 0-10V; 4-20 mA), etc..

With its 6 universal analogue channels and 16 logical inputs you can record long term measurements with a sampling rate of 1MHz taking full use of the 500GB internal hard disk memory. With a special integrated function of Power Analysis you can record all your parameters on a Single-Phase and Three-Phase network (50Hz, 400Hz and 1kHz).

This Data Acquisition Solution can be remotely controlled by USB, Ethernet or Wi-Fi connection and the results can be analysed on license-free software from Sefram.

Product Features

  • TFT panoramic LCD touch screen (15″6)
  • 6 isolated analogue channels:
  • 14 bit, 1 Ms/s, Bandwidth: 100kHz
  • DC, RMS AC+DC Voltage (+-500V)
  • Frequency, Thermocouples
  • 16 logic channels
  • 128 Mword memory, with segments
  • Internal hard disk : 500 Gb
  • Intuitive man-machine interface
  • Power Analysis function (50Hz, 400Hz and 1kHz)
  • Interfaces : 4 x USB, Ethernet, VGA
  • Various measurement functions
  • Remote control
  • Supplied with licence free Sefram Viewer software for data transfer and analysis
  • Safety: 600V CAT III

Options:

  • CAN – LIN bus (2 CAN ports, 2 LIN input) – factory option
  • Wi-Fi interface
  • Internal battery – factory option
  • 2 TB memory extension
  • GPS option – internal clock synchronisation with GPS time
  • High impedance input option
General Features
Capacitive backlight touch screen 15.6"
Screen Resolution 1366 x 768
Internal Hard Disk Memory 500 GB SSD (up to 2 TB with option)
Memory 128 Mwords divisible by 128 blocks
Weight 8Kg
Dimensions 271 x 472 x 154mm
Power Supply 99 VAC to 264 VAC, 47 to 63 Hz
Consumption 80 VA max
Operating Temperature 0 to 40°C
0 to 30°C with battery option or without fan
Storage Temperature -20 to 60°C
Interfaces 4 USB, 1 VGA, 1 Ethernet
Universal Input Board
Voltage
Number of Channels 6 isolated channels
DC Voltage Range 1mV to 1000 V
Maximum DC Voltage 500 V
Direct Voltage Accuracy ± 0.1 % of range
Bandwidth 100 kHz (-3 dB)
AC RMS Voltage Range 200 mV to 500 V
Maximum AC RMS Voltage 424 V
RMS voltage Accuracy 1 % of range
Bandwidth for RMS Measurement 5 Hz - 500 Hz
Crest Factor 2
Input Impedance 1 MΩ for ranges > 1 V / 25 MΩ for ranges < 1 V
High Impedance Input Option 10 MΩ for ranges > 1 V / 25 MΩ for ranges < 1V
Input Capacitance 150 pF
Frequency
Sensitivity 100 mV
Duty Cycle 10 %
Frequency Range 1 Hz to 100 kHz
Accuracy 0.02 % of range
Temperature
Thermocouple Type J, K, T, S, B ,E ,N, C, L: -250 °C to 1760 °C
Cold Junction Compensation ± 1.25 °C
Sampling
Vertical Resolution 14 bits
Maximum Direct Voltage Sampling Rate 1 MSa/s (1 μs) each channel
Maximum RMS Sampling Rate 5 kSa/s (200μs) each channel
Analogue Filters 100 Hz, 1 kHz, 10 kHz
Digital Filter Setting < 100 Hz
Safety CAT III - 500 V
Power Analysis Function
(this function can be used with one universal board and accessories for current measurements)
Networks single phase, three-phase
Frequency 50-60Hz, 400Hz and 1000Hz
Display oscilloscope, Fresnel diagram
Harmonics calculated up to rank 50, with recording capabilities
Measurements U and I (mean values, RMS, peak), crest factor, power (active, reactive, apparent), power factor, harmonics, THD, DF, frequency, energy



Supplied with:
Carrying Case, UK Power Cord, Logical Connector
Optional Accessories 16 channel isolated logic adapter
Patch cord for logical input
Banana / BNC female adaptor
Rackmount for DAS700
Wi-Fi option for DAS700
50 ohms shunt, 0.1%, 0.05A max
0.01 ohm shunt, 1%, 3A max
0.1 ohm shunt, 1%, 1A max
10 ohms shunt, 0.1%, 0.15A max
1 ohm shunt, 0.1%, 0.5A max
0.01 ohm shunt, 0.5%, 30A max
Flexible Current Clamp 3000A AC
