Product Features

• 5-digit digital display (reading scale -19999 to +99999)
• Static strain measurement
• Analogue voltage output supported.
• Hold Functions: Offers various hold modes including Peak, Bottom, Peak to Peak, and block-specified hold (Peak, Bottom, Peak to Peak).
• Data Output Options: Equipped with either BCD (Binary Coded Decimal) output or an RS-232C interface.
• Panel Mountable: Designed in a standard 1/4 DIN size for easy integration into manufacturing equipment panels.
• TEDS Compliant: Supports IEEE 1451.4 standards, enabling automatic setup and calibration when paired with a TEDS-enabled load cell, which eliminates the need for manual configuration.

Applications:

• Quality control
• Fabrication
• Advanced analysis
• General force measurement in industrial settings

The post TD-260T Digital Indicator appeared first on DAQLOG Systems Ltd.

The series can measure and display high-speed detailed phenomena faster and at a higher resolution than conventional sensors. The Rotation Torque Sensor is designed for in shaft torque measurement e.g. as used for test beds for powertrain development.

Product Features

• Torque sensor featuring 1/3000 high resolution and robust construction
• Robust against vibration: Sensor can be installed to Engine output shaft without intermediate bearing.
• Real torque measurement using component force measurement
• Dual range with high accuracy (without degrading the total accuracy)
• Nominal torque: 200Nm – 5kNm
• Combined error: 0.03%
• Dual range: Combined error of 1/3000 is guaranteed at 1/5 of full scale
• Maximum rpm: 12,000 rpm (200 Nm) – 10,000 rpm (5 kNm)

Please contact us with your specification requirements.

The post AD7832 Series Rotation Torque Sensor (RTS) appeared first on DAQLOG Systems Ltd.

Small and light weight.

TEDS compliant.

The post TU-QR(T)-G3 Tension – Compression Load Cell appeared first on DAQLOG Systems Ltd.

Product Features

• High-speed processing 25000 times/sec
• 4.3-inch wide touchscreen monitor mounted on a panel with 92 x 92 mm hole size.
• Displacement input as standard
• Analogue Output  0 to +-10V, or 4 to 20 mA
• Digital Output either RS-232C or USB
• TEDS Calibration
• Linearization Calibration
• Built-in memory and SD card drive
• Judgement result display function
• Load cell diagnostic functions:
  Static strain display
  Disconnection detection

Displacement Sensor Input

The post TD-9000T High-speed Digital Indicator for Load Management appeared first on DAQLOG Systems Ltd.

The TD-SC1 is a strain gauge signal conditioner which converts a minute electrical signal of a load cell into an output that matches the specifications of the control unit.
This product is mainly used for pressurising force control of load cells for semiconductor manufacturing equipment, industrial robots, FA equipment, etc.
In recent years, the introduction of IoT in production factories has accelerated rapidly. Amid the demand for improved productivity through centralized management, the TD-SC1 series meets that need.

Product Features

• Thin, compact, light-weight design
  30 x 85 x 110mm (w x h x d), 210g
• Din rail mountable
• TEDs calibration
• Digital filter
  3, 10, 30, 100, 300, 1000 Hz(−6 dB/oct) or Off as standard
• High-speed A/D conversion
  high-speed sampling of 20,000 times/sec
• Status indicator
• Fieldbuses RS-485, CC-Link, EtherNet/IP , etc.

The post TD-SC1 Strain Gauge Signal Conditioner Series appeared first on DAQLOG Systems Ltd.

The TC-WLD(T) is a ready-to-use strain-gauge load cell. It has been designed specifically for pressure force measurement on spot welding machines in industrial production lines. This load cell consists of a handy all-metal housing with a spring-loaded handle ensuring safe operation. The load cell comes with a 6-core shielded 1 meter cable with two robust PRC connectors as standard. This allows quick and safe connection with devices such as the TEAC TD-01 Portable indicator.

The TC-WLD(T) has many benefits. Firstly it can be used for forces up to 10 kN or 20 kN and has a safe overload handling of 120 percent. Additionally, linearity is as high as one percent (10 kN) or two percent (20 kN). Furthermore, the compensated temperature range from zero to 50 degrees Celsius guarantees exact measurement results even under adverse environmental conditions.

Lastly, the built-in Transducer Electronic Data Sheet (TEDS, IEEE 1451.4) allows auto-identification and auto-calibration of the load cell to ensure time-saving setup and avoid scaling and calibration errors.

Applications

• Ideal for measuring pressure force between electrodes of resistance welding machines, such as in spot welding of factory automation and automobile production lines.
• In combination with the digital TEAC TD-01 Portable indicator, on-site pressure calibration or control can be accomplished safely and easily.

Compression load cell for force measurement on spot welding machines in combination with the TD-01 portable indicator.

The post TC-WLD(T) Compression Load Cell appeared first on DAQLOG Systems Ltd.
